Please contact us for more photos of EEEFP1E221AP
| Part Number | EEEFP1E221AP |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 697400 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 220uF 25V 20% (8 X 10.2mm) SMD 0.08 Ohm 850mA 2000 hr 105\u00b0C Embossed T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEEFP1E221AP |
| Datasheet download |  EEEFP1E221AP.pdf |
| Part Number | EEEFP1E221AP |
|---|---|
| Operating Temperature | -55 to 105 °C |
| Lead Finish | Tin/Bismuth |
| Equivalent Series Resistance | 0.08 Ohm |
| Product Dimensions | 10.2 mm |
| Voltage(DC) | 25 V |
| Rad Hard | No |
| Tolerance | 20 % |
| Max Processing Temp | 260 |
| Ripple Current | 850 mA |
| Leakage Current | 55@2Min uA |
| Capacitance Value | 220 uF |
| Package/Case | 8 X 10.2 |
| Mounting | Surface Mount |
| Construction | Cylindrical |
| Lifetime | 2000 hr |
| Product Diameter | 8 mm |
| Product Height | 10.2 mm |
| Replacement Part Number | PART-EEEFP1E221AP |
| Weight | Contact us |
| Country of Origin | - |
