Please contact us for more photos of EEHZC1E101XP
| Part Number | EEHZC1E101XP |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 322810 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 100uF 25V 20% (6.3 X 7.7mm) Aluminum Cylindrical Can 0.03 Ohm 1400mA 4000 hr 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEHZC1E101XP |
| Datasheet download |  EEHZC1E101XP.pdf |
| Part Number | EEHZC1E101XP |
|---|---|
| Product Dimensions | 7.7 mm |
| Voltage(DC) | 25 V |
| Capacitance Value | 100 uF |
| Rad Hard | No |
| Equivalent Series Resistance | 0.03 Ohm |
| Tolerance | 20 % |
| Package/Case | 6.3 X 7.7 |
| Leakage Current | 25@2Min uA |
| Mounting | Surface Mount |
| Operating Temperature | -55 to 125 °C |
| Ripple Current | 1400 mA |
| Lifetime | 4000 hr |
| Construction | Aluminum Cylindrical Can |
| Product Diameter | 6.3 mm |
| Product Height | 7.7 mm |
| Replacement Part Number | PART-EEHZC1E101XP |
| Weight | Contact us |
| Country of Origin | - |
