ELL4LG220MA Panasonic

ELL4LG220MA Images

Please contact us for more photos of ELL4LG220MA

Part Number ELL4LG220MA
Manufacturer Panasonic
Quantity in stock 748610 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind Choke Coil Shielded 22uH 20% 100KHz 640mA 1515 Embossed Carrier T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level ELL4LG220MA
Datasheet download ELL4LG220MA.pdf
Request Quotation for ELL4LG220MA

ELL4LG220MA Specifications

Part Number ELL4LG220MA
Tolerance 20 %
Rad Hard No
Max Processing Temp 260
Test Frequency 100 kHz
Package/Case 1515
Product Dimensions 4 x 4 x 1.8 mm
Lead Finish Tin
Protection Style Shielded
Product Depth 4 mm
Product Height 1.8 mm
Product Length 4 mm
Replacement Part Number PART-ELL4LG220MA
Weight Contact us
Country of Origin -
