ERJ-3BQF4R7V Panasonic

ERJ-3BQF4R7V Images

Please contact us for more photos of ERJ-3BQF4R7V

Part Number ERJ-3BQF4R7V
Manufacturer Panasonic
Quantity in stock 378120 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Res Thick Film 0603 4.7 Ohm 1% 1 4W \u00b1300ppm \u00b0C Molded SMD SMD Punched Carrier T R
Category Resistor
Family Resistor Fixed Single-Surface Mount
ROHS Compliant Yes
MSL Level ERJ-3BQF4R7V
Datasheet download ERJ-3BQF4R7V.pdf
Request Quotation for ERJ-3BQF4R7V

ERJ-3BQF4R7V Specifications

Part Number ERJ-3BQF4R7V
Temperature Coefficient ±300 ppm/°C
Power Rating 0.25 W
Max Processing Temp 260
Resistance Value 4.7 Ohm
Product Dimensions 1.6 x 0.8 x 0.45 mm
Operating Temperature -55 to 125 °C
Rad Hard No
Mounting Surface Mount
Lead Finish Tin
Case Size 0603
Case Style Molded
Tolerance 1 %
Product Depth 0.8 mm
Product Height 0.45 mm
Product Length 1.6 mm
Product Weight 2 mg
Replacement Part Number PART-ERJ-3BQF4R7V
Weight Contact us
Country of Origin -
