Please contact us for more photos of ERJ12YJ1R5U
| Part Number | ERJ12YJ1R5U |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 579550 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film 1812 1.5 Ohm 5% 3 4W -100ppm \u00b0C to 600ppm \u00b0C Molded SMD SMD Embossed Carrier T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | ERJ12YJ1R5U |
| Datasheet download |  ERJ12YJ1R5U.pdf |
| Part Number | ERJ12YJ1R5U |
|---|---|
| Temperature Coefficient | -100 to 600 ppm/°C |
| Mounting | Surface Mount |
| Lead Finish | Tin |
| Operating Temperature | -55 to 155 °C |
| Product Dimensions | 4.5 x 3.2 x 0.6 mm |
| Power Rating | 0.75 W |
| Case Size | 1812 |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Tolerance | 5 % |
| Case Style | Molded |
| Resistance Value | 1.5 Ohm |
| Product Depth | 3.2 mm |
| Product Height | 0.6 mm |
| Product Length | 4.5 mm |
| Product Weight | 27 mg |
| Replacement Part Number | PART-ERJ12YJ1R5U |
| Weight | Contact us |
| Country of Origin | - |
