Please contact us for more photos of ERJU01J220C
| Part Number | ERJU01J220C |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 534490 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film 0201 22 Ohm 5% 1 20W \u00b1200ppm \u00b0C Molded SMD Pressed Paper T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | ERJU01J220C |
| Datasheet download |  ERJU01J220C.pdf |
| Part Number | ERJU01J220C |
|---|---|
| Mounting | Surface Mount |
| Power Rating | 0.05 W |
| Case Size | 0201 |
| Product Dimensions | 0.6 x 0.3 x 0.23 |
| Lead Finish | Tin |
| Supplier Package | 0201 |
| Operating Temperature | -55 to 155 °C |
| Tolerance | 5 % |
| Pin Count | 2 |
| Temperature Coefficient | ±200 ppm/°C |
| Rad Hard | No |
| Case Style | Molded |
| Max Processing Temp | 260 |
| Termination Style | Wraparound |
| Resistance Value | 22 Ohm |
| Product Depth | 0.3 mm |
| Product Height | 0.23 mm |
| Product Length | 0.6 mm |
| Product Weight | 0.15 mg |
| Replacement Part Number | PART-ERJU01J220C |
| Weight | Contact us |
| Country of Origin | - |
