Please contact us for more photos of P1170.222NLT
| Part Number | P1170.222NLT |
|---|---|
| Manufacturer | Pulse |
| Quantity in stock | 353060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Shielded Wirewound 2.2uH 30% 100KHz 9.6A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | P1170.222NLT |
| Datasheet download |  P1170.222NLT.pdf |
| Part Number | P1170.222NLT |
|---|---|
| Technology | Wirewound |
| Rad Hard | No |
| Test Frequency | 100 kHz |
| Type | Power |
| Operating Temperature | -40 to 130 °C |
| Product Dimensions | 12.24 x 12.24 x 6 mm |
| Protection Style | Shielded |
| Tolerance | 30 % |
| Package/Case | 12.24 X 12.24 X 6 |
| Product Depth | 12.24 mm |
| Product Height | 6 mm |
| Product Length | 12.24 mm |
| Replacement Part Number | PART-P1170.222NLT |
| Weight | Contact us |
| Country of Origin | - |
