Please contact us for more photos of PB2020.223NLT
| Part Number | PB2020.223NLT |
|---|---|
| Manufacturer | Pulse |
| Quantity in stock | 848210 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Unshielded Wirewound 22uH 20% 8.1A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | PB2020.223NLT |
| Datasheet download |  PB2020.223NLT.pdf |
| Part Number | PB2020.223NLT |
|---|---|
| Protection Style | Unshielded |
| Technology | Wirewound |
| Rad Hard | No |
| Max Processing Temp | 245 |
| Tolerance | 20 % |
| Type | Power |
| Product Dimensions | 23.87 x 20.83 x 10.16 mm |
| Operating Temperature | -40 to 130 °C |
| Package/Case | 23.87 X 20.83 X 10.16 |
| Product Depth | 20.83 mm |
| Product Height | 10.16 mm |
| Product Length | 23.87 mm |
| Replacement Part Number | PART-PB2020.223NLT |
| Weight | Contact us |
| Country of Origin | - |
