Please contact us for more photos of PF0601.552NLT
| Part Number | PF0601.552NLT |
|---|---|
| Manufacturer | Pulse |
| Quantity in stock | 361140 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Shielded Wirewound 5.5uH 20% 100KHz 1.5A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | PF0601.552NLT |
| Datasheet download |  PF0601.552NLT.pdf |
| Part Number | PF0601.552NLT |
|---|---|
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 125 °C |
| Technology | Wirewound |
| Rad Hard | No |
| Tolerance | 20 % |
| Type | Power |
| Test Frequency | 100 kHz |
| Package/Case | 6.9 X 6.5 X 3 |
| Protection Style | Shielded |
| Product Dimensions | 6.9 x 6.5 x 3 mm |
| Product Depth | 6.5 mm |
| Product Height | 3 mm |
| Product Length | 6.9 mm |
| Replacement Part Number | PART-PF0601.552NLT |
| Weight | Contact us |
| Country of Origin | - |
