Please contact us for more photos of BAS29
| Part Number | BAS29 |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 119710 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Small Signal Switching 120V 0.2A 3-Pin SOT-23 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAS29 |
| Datasheet download |  BAS29.pdf |
| Part Number | BAS29 |
|---|---|
| Peak Reverse Current | 0.1 uA |
| Type | Small Signal Switching Diode |
| Peak Forward Voltage | [email protected] V |
| Product Dimensions | 2.92 x 1.3 x 0.93 mm |
| Peak Non-Repetitive Surge Current | 2 A |
| Lead Finish | Matte Tin |
| Peak Reverse Repetitive Voltage | 120 V |
| Supplier Package | SOT-23 |
| Operating Temperature | -55 to 150 °C |
| Peak Reverse Recovery Time | 50 ns |
| Rad Hard | No |
| Mounting | Surface Mount |
| Peak Average Forward Current | 0.2 A |
| Pin Count | 3 |
| MSL Level | 1 |
| Configuration | Single |
| Max Processing Temp | 260 |
| Package | 3SOT-23 |
| Replacement Part Number | PART-BAS29 |
| Weight | Contact us |
| Country of Origin | - |
