Please contact us for more photos of BAS70,215
| Part Number | BAS70,215 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 749140 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 70V 0.07A 3-Pin TO-236AB T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAS70,215 |
| Datasheet download |  BAS70,215.pdf |
| Part Number | BAS70,215 |
|---|---|
| Mounting | Surface Mount |
| MSL Level | 1 |
| Pin Count | 3 |
| Configuration | Single |
| Product Dimensions | 3 x 1.4 x 1 mm |
| Lead Finish | Tin |
| Peak Reverse Repetitive Voltage | 70 V |
| Peak Average Forward Current | 0.07 A |
| Peak Non-Repetitive Surge Current | 0.1 A |
| Peak Forward Voltage | [email protected] V |
| Supplier Package | TO-236AB |
| Operating Temperature | -65 to 150 °C |
| Rad Hard | No |
| Peak Reverse Current | 10 uA |
| Max Processing Temp | 260 |
| Type | Schottky Diode |
| Package | 3TO-236AB |
| Replacement Part Number | PART-BAS70,215 |
| Weight | Contact us |
| Country of Origin | - |
