Please contact us for more photos of NTSJ2080CTG
| Part Number | NTSJ2080CTG |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 129510 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 80V 20A 3-Pin(3+Tab) TO-220FP Rail |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | NTSJ2080CTG |
| Datasheet download |  NTSJ2080CTG.pdf |
| Part Number | NTSJ2080CTG |
|---|---|
| Peak Forward Voltage | 0.83@10A V |
| Peak Reverse Current | 600 uA |
| Peak Non-Repetitive Surge Current | 150 A |
| Mounting | Through Hole |
| Max Processing Temp | 260 |
| Product Dimensions | 10.3 x 4.7 x 8.2 mm |
| Configuration | Dual Common Cathode |
| Type | Schottky Diode |
| Peak Average Forward Current | 20 A |
| Peak Reverse Repetitive Voltage | 80 V |
| Lead Finish | Matte Tin |
| Pin Count | 3 |
| Supplier Package | TO-220FP |
| Operating Temperature | -40 to 150 °C |
| Rad Hard | No |
| Package | 3TO-220FP |
| Replacement Part Number | PART-NTSJ2080CTG |
| Weight | Contact us |
| Country of Origin | - |
