Please contact us for more photos of SM260AF
| Part Number | SM260AF |
|---|---|
| Manufacturer | Leshan Radio |
| Quantity in stock | 420390 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | SCHOTTKY BARRIER RECTIFIERS CURRECT 2.0 |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | SM260AF |
| Datasheet download |  SM260AF.pdf |
| Part Number | SM260AF |
|---|---|
| Packaging | Tape and Reel |
| Green | Yes |
| Peak Forward Voltage | 0.7@2A V |
| Rad Hard | No |
| Configuration | Single |
| Type | Schottky Diode |
| Peak Average Forward Current | 2@Tc=75C A |
| Mounting | Surface Mount |
| Family | SM260AF |
| Peak Reverse Repetitive Voltage | 60 V |
| Peak Reverse Current | 500@60V uA |
| Operating Temperature | -40 to 150 °C |
| Lead Free | Yes |
| Peak Non-Repetitive Surge Current | 60 A |
| Package | 2SMA-FL |
| Replacement Part Number | PART-SM260AF |
| Weight | Contact us |
| Country of Origin | - |
