MCR01MZPF5113 ROHM

MCR01MZPF5113 Images

Please contact us for more photos of MCR01MZPF5113

Part Number MCR01MZPF5113
Manufacturer ROHM
Quantity in stock 458560 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Res Thick Film 0402 511K Ohm 1% 1 16W \u00b1100ppm \u00b0C Molded SMD SMD Paper T R
Category Resistor
Family Resistor Fixed Single-Surface Mount
ROHS Compliant Yes
MSL Level MCR01MZPF5113
Datasheet download MCR01MZPF5113.pdf
Request Quotation for MCR01MZPF5113

MCR01MZPF5113 Specifications

Part Number MCR01MZPF5113
Military Standard
Failure Rate
Resistance Value 511 kOhm
Product Dimensions 1 x 0.5 x 0.35 mm
Rad Hard No
Case Style Molded
Type Thick Film
Lead Finish Matte Tin
Mounting Surface Mount
Max Processing Temp 260|265
Case Size 0402
Operating Temperature -55 to 155 °C
Temperature Coefficient ±100 ppm/°C
Tolerance 1 %
Package Type SMD
Power Rating 0.0625 W
Product Depth 0.5 mm
Product Height 0.35 mm
Product Length 1 mm
Product Weight 0.7 mg
Replacement Part Number PART-MCR01MZPF5113
Weight Contact us
Country of Origin -
