Please contact us for more photos of MCR10EZPF2152
| Part Number | MCR10EZPF2152 |
|---|---|
| Manufacturer | ROHM |
| Quantity in stock | 507160 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film 0805 21.5K Ohm 1% 1 8W \u00b1100ppm \u00b0C Molded SMD Paper T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | MCR10EZPF2152 |
| Datasheet download |  MCR10EZPF2152.pdf |
| Part Number | MCR10EZPF2152 |
|---|---|
| Type | Thick Film |
| Package Dimensions | 2 x 1.25 x 0.55 mm |
| Rad Hard | No |
| Case Style | Molded |
| Supplier Package | 0805 |
| Pin Count | 2 |
| Termination Style | Wraparound |
| Mounting | Surface Mount |
| Operating Temperature | -55 to 155 °C |
| Temperature Coefficient | ±100 ppm/°C |
| Tolerance | 1 % |
| Case Size | 0805 |
| Resistance Value | 21.5 kOhm |
| Maximum Processing Temperature | 260 °C |
| Lead Finish | Tin Over Nickel |
| Product Depth | 1.25 mm |
| Product Height | 0.55 mm |
| Product Length | 2 mm |
| Replacement Part Number | PART-MCR10EZPF2152 |
| Weight | Contact us |
| Country of Origin | - |
