Please contact us for more photos of MCR18EZHJ273
| Part Number | MCR18EZHJ273 |
|---|---|
| Manufacturer | ROHM |
| Quantity in stock | 551900 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film 1206 27K Ohm 5% 1 4W \u00b1200ppm \u00b0C Molded SMD Paper T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | MCR18EZHJ273 |
| Datasheet download |  MCR18EZHJ273.pdf |
| Part Number | MCR18EZHJ273 |
|---|---|
| Maximum Processing Temperature | 260 °C |
| Type | Thick Film |
| Case Style | Molded |
| Pin Count | 2 |
| Rad Hard | No |
| Temperature Coefficient | ±200 ppm/°C |
| Supplier Package | 1206 |
| Tolerance | 5 % |
| Case Size | 1206 |
| Termination Style | Wraparound |
| Resistance Value | 27 kOhm |
| Mounting | Surface Mount |
| Package Dimensions | 3.2 x 1.6 x 0.55 mm |
| Operating Temperature | -55 to 155 °C |
| Lead Finish | Tin Over Nickel |
| Product Depth | 1.6 mm |
| Product Height | 0.55 mm |
| Product Length | 3.2 mm |
| Replacement Part Number | PART-MCR18EZHJ273 |
| Weight | Contact us |
| Country of Origin | - |
