Please contact us for more photos of ERM8-075-03-L-D-RA-K-TR
| Part Number | ERM8-075-03-L-D-RA-K-TR |
|---|---|
| Manufacturer | Samtec |
| Quantity in stock | 708440 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Micro High Speed Terminal Strip HDR 150 POS 0.8mm Solder RA Thru-Hole T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | ERM8-075-03-L-D-RA-K-TR |
| Datasheet download |  ERM8-075-03-L-D-RA-K-TR.pdf |
| Part Number | ERM8-075-03-L-D-RA-K-TR |
|---|---|
| Termination Method | Solder |
| Pitch | 0.8 mm |
| Housing Color | Black |
| Gender | HDR |
| Body Orientation | Right Angle |
| Mounting | Through Hole |
| Operating Temperature | -55 to 125 °C |
| Product Dimensions | 73 x 15.36 x 6.25 mm |
| Housing Material | Liquid Crystal Polymer |
| Rad Hard | No |
| Contact Material | Phosphor Bronze |
| Contact Plating | Gold Over Nickel |
| Product Depth | 15.36 mm |
| Product Height | 6.25 mm |
| Product Length | 73 mm |
| Replacement Part Number | PART-ERM8-075-03-L-D-RA-K-TR |
| Weight | Contact us |
| Country of Origin | - |
