Please contact us for more photos of SM6T200CA
| Part Number | SM6T200CA |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 885300 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode TVS Single Bi-Dir 171V 600W 2-Pin SMB T R |
| Category | Circuit Protection |
| Family | TVS |
| ROHS Compliant | Yes |
| MSL Level | SM6T200CA |
| Datasheet download |  SM6T200CA.pdf |
| Part Number | SM6T200CA |
|---|---|
| Peak Pulse Power Dissipation | 600 W |
| Supplier Package | SMB |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Minimum Breakdown Voltage | 190 V |
| Maximum Reverse Stand-off Voltage | 171 V |
| MSL Level | 1 |
| ESD Protection | No |
| Maximum Clamping Voltage | 353 V |
| Maximum Peak Pulse Current | 11.3 A |
| Direction Type | Bi-Directional |
| Pin Count | 2 |
| Test Current | 1 mA |
| Rad Hard | No |
| Maximum Reverse Leakage Current | 0.2 uA |
| Operating Temperature | -55 to 150 °C |
| Product Dimensions | 4.6 x 3.95 x 2.45 mm |
| Max Processing Temp | 260 |
| Configuration | Single |
| Package | 2SMB |
| Replacement Part Number | PART-SM6T200CA |
| Weight | Contact us |
| Country of Origin | - |
