Please contact us for more photos of STM32F100C8T7B
| Part Number | STM32F100C8T7B |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 342890 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 32-bit STM32F ARM Cortex M3 RISC 64KB Flash 2.5V 3.3V 48-Pin LQFP |
| Category | Microcontrollers MCU IC |
| Family | ARM Based Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | STM32F100C8T7B |
| Datasheet download |  STM32F100C8T7B.pdf |
| Part Number | STM32F100C8T7B |
|---|---|
| Data Bus Width | 32 Bit |
| Maximum Speed | 24 MHz |
| Rad Hard | No |
| Number of Programmable I/Os | 37 |
| Interface Type | I2C/SPI/USART |
| Watchdog | 2 |
| MSL Level | 3 |
| Device Core | ARM Cortex M3 |
| Maximum Power Dissipation | 363 mW |
| Program Memory Size | 64 KB |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Minimum Operating Supply Voltage | 2 V |
| RAM Size | 8 KB |
| Operating Supply Voltage | 2.5|3.3 V |
| Number of Timers | 7 |
| On-Chip DAC | 2(2-chx12-bit) |
| Display Driver | |
| Data Memory Size | |
| Maximum Expanded Memory Size | |
| LCD Segments | |
| On-Chip ADC | 10-chx12-bit |
| Pin Count | 48 |
| Instruction Set Architecture | RISC |
| Program Memory Type | Flash |
| Supplier Package | LQFP |
| Lead Finish | Gold |
| Maximum Operating Supply Voltage | 3.6 V |
| Operating Temperature | -40 to 105 °C |
| Screening Level | Industrial |
| Product Dimensions | 7 x 7 x 1.4 mm |
| Package | 48LQFP |
| Replacement Part Number | PART-STM32F100C8T7B |
| Weight | Contact us |
| Country of Origin | - |
