Please contact us for more photos of EVQQ2503W
| Part Number | EVQQ2503W |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 511980 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Switch Tactile N.O. SPST Round Button J-Bend 20A 250VAC15VDC SMD Embossed T R |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | EVQQ2503W |
| Datasheet download |  EVQQ2503W.pdf |
| Part Number | EVQQ2503W |
|---|---|
| Switch Configuration | N.O. |
| Operating Temperature | -40 to 85 °C |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Mounting | Surface Mount |
| Product Dimensions | 6.5 x 6 x 3.1 |
| Pole Throw Configuration | SPST |
| Pin Count | 4 |
| Replacement Part Number | PART-EVQQ2503W |
| Weight | Contact us |
| Country of Origin | - |
