Please contact us for more photos of HK100522NJ-T
| Part Number | HK100522NJ-T |
|---|---|
| Manufacturer | TAIYO YUDEN |
| Quantity in stock | 671270 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind High Frequency Chip Multi-Layer 22nH 5% 100MHz 8Q-Factor Ceramic 300mA 0402 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | HK100522NJ-T |
| Datasheet download |  HK100522NJ-T.pdf |
| Part Number | HK100522NJ-T |
|---|---|
| Operating Temperature | -55 to 125 °C |
| Technology | Multi-Layer |
| Product Dimensions | 1.05 x 0.55 x 0.55 mm |
| Test Frequency | 100 MHz |
| Package/Case | 0402 |
| Rad Hard | No |
| Tolerance | 5 % |
| Max Processing Temp | 260 |
| Product Depth | 0.55 mm |
| Product Height | 0.55 mm |
| Product Length | 1.05 mm |
| Replacement Part Number | PART-HK100522NJ-T |
| Weight | Contact us |
| Country of Origin | - |
