Please contact us for more photos of B82799C224N1
| Part Number | B82799C224N1 |
|---|---|
| Manufacturer | TDK |
| Quantity in stock | 156980 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Choke 220uH 30% 100KHz Ferrite 200mA 1812 Blister T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | B82799C224N1 |
| Datasheet download |  B82799C224N1.pdf |
| Part Number | B82799C224N1 |
|---|---|
| Maximum DC Resistance | |
| Maximum DC Current | 200 |
| Type | Choke |
| Rad Hard | No |
| Core Material | Ferrite |
| Lead Finish | Gold |
| Test Frequency | 100 kHz |
| Product Dimensions | 4.7 x 3.4 x 3.2 mm |
| Max Processing Temp | 250 |
| Tolerance | 30 % |
| MSL Level | 1 |
| Inductance | 51 |
| Package/Case | 1812 |
| Product Depth | 3.4 mm |
| Product Height | 3.2 mm |
| Product Length | 4.7 mm |
| Replacement Part Number | PART-B82799C224N1 |
| Weight | Contact us |
| Country of Origin | - |
