B82799S 223N 1 TDK

B82799S 223N 1 Images

Please contact us for more photos of B82799S 223N 1

Part Number B82799S 223N 1
Manufacturer TDK
Quantity in stock 138280 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind Choke 22uH 30% 100KHz Ferrite 250mA 1812 Blister T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level B82799S 223N 1
Datasheet download B82799S 223N 1.pdf
Request Quotation for B82799S 223N 1

B82799S 223N 1 Specifications

Part Number B82799S 223N 1
Tolerance 30 %
MSL Level 1
Inductance 51
Package/Case 1812
Test Frequency 100 kHz
Product Dimensions 4.7 x 3.4 x 3.2 mm
Max Processing Temp 250
Maximum DC Resistance
Maximum DC Current 200
Type Choke
Rad Hard No
Core Material Ferrite
Lead Finish Gold
Product Depth 3.4 mm
Product Height 3.2 mm
Product Length 4.7 mm
Replacement Part Number PART-B82799S 223N 1
Weight Contact us
Country of Origin -
