Please contact us for more photos of SRP1265A-220M
| Part Number | SRP1265A-220M |
|---|---|
| Manufacturer | Bourns |
| Quantity in stock | 464830 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Shielded 22uH 20% 100KHz Carbonyl Powder 9A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | SRP1265A-220M |
| Datasheet download |  SRP1265A-220M.pdf |
| Part Number | SRP1265A-220M |
|---|---|
| Protection Style | Shielded |
| Core Material | Carbonyl Powder |
| Package/Case | 12.5 X 12.5 X 6.2 |
| Supplier Package | SMD |
| Lead Finish | Tin |
| Operating Temperature | -40 to 150 °C |
| Rad Hard | No |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Product Dimensions | 12.5 x 12.5 x 6.2 |
| Tolerance | 20 % |
| Pin Count | 2 |
| Test Frequency | 100 kHz |
| Type | Power |
| Product Depth | 12.5 mm |
| Product Height | 6.2 mm |
| Product Length | 12.5 mm |
| Replacement Part Number | PART-SRP1265A-220M |
| Weight | Contact us |
| Country of Origin | - |
