Please contact us for more photos of 4922R-26L
| Part Number | 4922R-26L |
|---|---|
| Manufacturer | API Delevan |
| Quantity in stock | 134720 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind High Current Power Molded Unshielded Wirewound 120uH 15% 1KHz Ferrite 730mA 4922 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | 4922R-26L |
| Datasheet download |  4922R-26L.pdf |
| Part Number | 4922R-26L |
|---|---|
| Test Frequency | 1 kHz |
| Package/Case | 4922 |
| Technology | Wirewound |
| Rad Hard | No |
| Core Material | Ferrite |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Product Dimensions | 13.21 x 6.35 x 5.84 mm |
| Tolerance | 15 % |
| Type | High Current Power |
| Lead Finish | Tin |
| Protection Style | Molded/Unshielded |
| Operating Temperature | -55 to 125 °C |
| Product Depth | 6.35 mm |
| Product Height | 5.84 mm |
| Product Length | 13.21 mm |
| Replacement Part Number | PART-4922R-26L |
| Weight | Contact us |
| Country of Origin | - |
