Please contact us for more photos of 3-641215-2
| Part Number | 3-641215-2 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 816340 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 2 POS 2.54mm Solder ST Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 3-641215-2 |
| Datasheet download |  3-641215-2.pdf |
| Part Number | 3-641215-2 |
|---|---|
| Termination Method | Solder |
| Housing Color | White |
| Body Orientation | Straight |
| Max Processing Temp | 240|260|265 |
| Product Dimensions | 5.08 x 5.71 x 10.03 mm |
| Lead Finish | Tin |
| Gender | HDR |
| Mounting | Through Hole |
| Rad Hard | No |
| Housing Material | Polyester |
| Contact Material | Copper Alloy |
| Family Name | Mass Termination Assembly (MTA) Connectors |
| Pitch | 2.54 mm |
| Contact Plating | Gold Over Nickel |
| Operating Temperature | -55 to 105 °C |
| Product Depth | 5.71 mm |
| Product Height | 10.03 mm |
| Product Length | 5.08 mm |
| Replacement Part Number | PART-3-641215-2 |
| Weight | Contact us |
| Country of Origin | - |
