Please contact us for more photos of 4-794638-4
| Part Number | 4-794638-4 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 206180 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Power HDR 14 POS 3mm Solder ST SMD 14 Terminal 1 Port |
| Category | Connectors |
| Family | Connector Power |
| ROHS Compliant | Yes |
| MSL Level | 4-794638-4 |
| Datasheet download |  4-794638-4.pdf |
| Part Number | 4-794638-4 |
|---|---|
| Max Processing Temp | 245|260 |
| Housing Material | Nylon |
| Mounting | Surface Mount |
| Termination Method | Solder |
| Lead Finish | Matte Tin |
| Body Orientation | Straight |
| Gender | HDR |
| Pitch | 3 mm |
| Product Dimensions | 25 x 10.94 x 9.24 mm |
| Contact Material | Brass |
| Operating Temperature | -40 to 105 °C |
| Rad Hard | No |
| Contact Plating | Gold Over Nickel |
| Product Depth | 10.94 mm |
| Product Height | 9.24 mm |
| Product Length | 25 mm |
| Replacement Part Number | PART-4-794638-4 |
| Weight | Contact us |
| Country of Origin | - |
