Please contact us for more photos of 5-146268-1
| Part Number | 5-146268-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 584890 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Unshrouded Header HDR 2 POS Solder ST Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 5-146268-1 |
| Datasheet download |  5-146268-1.pdf |
| Part Number | 5-146268-1 |
|---|---|
| Housing Color | Black |
| Gender | HDR |
| Product Dimensions | 2.13 x 4.88 x 8.13 mm |
| Operating Temperature | -65 to 105 °C |
| Lead Finish | Matte Tin|Tin |
| Contact Material | Phosphor Bronze |
| Contact Plating | Gold Over Nickel |
| Mounting | Through Hole |
| Housing Material | Thermoplastic |
| Rad Hard | No |
| Body Orientation | Straight |
| Termination Method | Solder |
| Max Processing Temp | 240|245|260|265 |
| Product Depth | 4.88 mm |
| Product Height | 8.13 mm |
| Product Length | 2.13 mm |
| Replacement Part Number | PART-5-146268-1 |
| Weight | Contact us |
| Country of Origin | - |
