Please contact us for more photos of 5179031-5
| Part Number | 5179031-5 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 526130 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Fine Pitch Connector PL 120 POS 0.8mm Solder ST SMD Tube |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 5179031-5 |
| Datasheet download |  5179031-5.pdf |
| Part Number | 5179031-5 |
|---|---|
| Contact Plating | Gold Over Nickel |
| Contact Material | Brass |
| Max Processing Temp | 245|260 |
| Housing Material | Liquid Crystal Polymer |
| Pitch | 0.8 mm |
| Gender | PL |
| Rad Hard | No |
| Housing Color | Natural |
| Family Name | Free Height (FH) Board-to-Board Connectors |
| Mounting | Surface Mount |
| Product Dimensions | 53.8 x 6 x 7.6 mm |
| Termination Method | Solder |
| Lead Finish | Tin |
| Body Orientation | Straight |
| Product Depth | 6 mm |
| Product Height | 7.6 mm |
| Product Length | 53.8 mm |
| Replacement Part Number | PART-5179031-5 |
| Weight | Contact us |
| Country of Origin | - |
