Please contact us for more photos of 6-103644-3
| Part Number | 6-103644-3 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 174670 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn IDC Connector RCP 14 POS 2.54mm IDT ST Cable Mount Individual |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 6-103644-3 |
| Datasheet download |  6-103644-3.pdf |
| Part Number | 6-103644-3 |
|---|---|
| Pitch | 2.54 mm |
| Rad Hard | No |
| Contact Plating | Gold Over Nickel |
| Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic |
| Mounting | Cable Mount |
| Housing Color | Black |
| Termination Method | IDT |
| Body Orientation | Straight |
| Lead Finish | Tin |
| Product Dimensions | 35.5 x 15.24 mm |
| Operating Temperature | -65 to 105 °C |
| Gender | RCP |
| Product Depth | 15.24 mm |
| Product Length | 35.5 mm |
| Replacement Part Number | PART-6-103644-3 |
| Weight | Contact us |
| Country of Origin | - |
