Please contact us for more photos of ADC128D818CIMTX NOPB
| Part Number | ADC128D818CIMTX NOPB |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 393320 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single Delta-Sigma 10sps 12-bit Serial 16-Pin TSSOP T R |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | ADC128D818CIMTX NOPB |
| Datasheet download |  ADC128D818CIMTX NOPB.pdf |
| Part Number | ADC128D818CIMTX NOPB |
|---|---|
| Number of ADCs | 1 |
| Differential Input | Yes |
| Architecture | Delta-Sigma |
| Sampling Rate | 10 sps |
| Maximum Single Supply Voltage | 5.5 V |
| Pin Count | 16 |
| Rad Hard | No |
| Typical Single Supply Voltage | 3.3|5 V |
| Product Dimensions | 5 x 4.4 x 0.9 mm |
| Input Signal Type | Single-Ended|Pseudo-Differential |
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 125 °C |
| Voltage Supply Source | Single |
| Digital Interface Type | Serial (I2C) |
| Input Voltage | 2.56 V |
| Sample and Hold | No |
| Digital Supply Support | No |
| Single-Ended Input | Yes |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Input Type | Voltage |
| Supplier Package | TSSOP |
| Polarity of Input Voltage | Unipolar |
| Differential Nonlinearity | ±1 LSB |
| Resolution | 12 Bit |
| Typical Power Dissipation | 2.01 mW |
| Minimum Single Supply Voltage | 3 V |
| Number of Analog Inputs | 8|4 |
| Full Scale Error | 0.45 % of FSR |
| MSL Level | 1 |
| Voltage Reference | Internal|External |
| Integral Nonlinearity Error | -2/4 LSB |
| Package | 16TSSOP |
| Replacement Part Number | PART-ADC128D818CIMTX NOPB |
| Weight | Contact us |
| Country of Origin | - |
