| Part Number | ADS8509IDBR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 846860 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single SAR 250ksps 16-bit Serial 28-Pin SSOP T R |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | ADS8509IDBR |
| Datasheet download |  ADS8509IDBR.pdf |
| Part Number | ADS8509IDBR |
|---|---|
| Resolution | 16 Bit |
| Lead Finish | Gold |
| Digital Interface Type | Serial (SPI) |
| Signal to Noise Ratio | 88 dB |
| Polarity of Input Voltage | Unipolar|Bipolar |
| Supplier Package | SSOP |
| Digital Supply Support | Yes |
| Number of ADCs | 1 |
| Maximum Single Supply Voltage | 5.25 V |
| Voltage Supply Source | Analog and Digital |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Input Signal Type | Single-Ended |
| MSL Level | 2 |
| Sampling Rate | 250 ksps |
| Architecture | SAR |
| Minimum Single Supply Voltage | 4.75 V |
| Sample and Hold | Yes |
| Mounting | Surface Mount |
| Pin Count | 28 |
| No Missing Codes | 15 Bit |
| Input Type | Voltage |
| Typical Power Dissipation | 70 mW |
| Maximum Power Dissipation | 100 mW |
| Integral Nonlinearity Error | ±3 LSB |
| Differential Input | No |
| Voltage Reference | Internal|External |
| Full Scale Error | 0.5 % of FSR |
| Typical Single Supply Voltage | 5 V |
| Product Dimensions | 10.2 x 5.3 x 1.95 mm |
| Screening Level | Industrial |
| Input Voltage | 4/5/10|V/5V/10V|±3.33V/±5V/±10V V |
| Differential Nonlinearity | ±2 LSB |
| Number of Analog Inputs | 1 |
| Single-Ended Input | Yes |
| Package | 28SSOP |
| Replacement Part Number | PART-ADS8509IDBR |
| Weight | Contact us |
| Country of Origin | - |
