LMZ23603TZX NOPB Texas Instruments

LMZ23603TZX NOPB Images

Please contact us for more photos of LMZ23603TZX NOPB

Part Number LMZ23603TZX NOPB
Manufacturer Texas Instruments
Quantity in stock 454440 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Module DC-DC 1-OUT 0.8V to 6V 3A 18W 7-Pin TO-PMOD EP T R
Category Power Supplies
Family DC to DC Power Supply
ROHS Compliant Yes
MSL Level LMZ23603TZX NOPB
Datasheet download LMZ23603TZX NOPB.pdf
Request Quotation for LMZ23603TZX NOPB

LMZ23603TZX NOPB Specifications

Part Number LMZ23603TZX NOPB
Mounting Surface Mount
Lead Finish Matte Tin
Input Voltage 6 to 36 V
Output Power 18 W
Output Voltage 0.8 to 6 V
Number of Outputs 1
Output Current 3 A
Max Processing Temp 245
MSL Level 3
Switching Regulator Yes
Type Step Down
Pin Count 7
Product Dimensions 10.16 x 9.85 x 4.57 mm
Supplier Package TO-PMOD EP
Rad Hard No
Package 7TO-PMOD EP
Replacement Part Number PART-LMZ23603TZX NOPB
Weight Contact us
Country of Origin -
