Please contact us for more photos of PTH05050WAH
| Part Number | PTH05050WAH |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 661060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Module DC-DC 1-OUT 0.8V to 3.6V 6A 6-Pin DIP Module Tray |
| Category | Power Supplies |
| Family | DC to DC Power Supply |
| ROHS Compliant | Yes |
| MSL Level | PTH05050WAH |
| Datasheet download |  PTH05050WAH.pdf |
| Part Number | PTH05050WAH |
|---|---|
| Lead Finish | Matte Tin |
| Input Voltage | 5(TYP) V |
| Type | Step Down |
| Mounting | Through Hole |
| Pin Count | 6 |
| Switching Regulator | Yes |
| Output Current | 6 A |
| Number of Outputs | 1 |
| Product Dimensions | 22.1 x 12.57 x 8.25 mm |
| Supplier Package | DIP Module |
| Output Voltage | 0.8 to 3.6 V |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Package | 6DIP Module |
| Replacement Part Number | PART-PTH05050WAH |
| Weight | Contact us |
| Country of Origin | - |
