Please contact us for more photos of SN74CB3T16210DGGR
| Part Number | SN74CB3T16210DGGR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 322180 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Bus Switch 2-Element CMOS 20-IN 48-Pin TSSOP T R |
| Category | Logic & Timing IC |
| Family | Bus Switch |
| ROHS Compliant | Yes |
| MSL Level | SN74CB3T16210DGGR |
| Datasheet download |  SN74CB3T16210DGGR.pdf |
| Part Number | SN74CB3T16210DGGR |
|---|---|
| Product Dimensions | 12.5 x 6.1 x 1.15 mm |
| Maximum Propagation Delay Time @ Maximum CL | [email protected] ns |
| Mounting | Surface Mount |
| Supplier Package | TSSOP |
| Number of Elements per Chip | 2 |
| Maximum High Level Output Current | -128 mA |
| Maximum On Resistance | 5 Ohm |
| Screening Level | Commercial |
| Minimum Operating Supply Voltage | 2.3 V |
| MSL Level | 1 |
| Maximum Quiescent Current | 40 uA |
| Typical Operating Supply Voltage | 2.5|3.3 V |
| Pin Count | 48 |
| Number of Outputs per Chip | 20 |
| Maximum Low Level Output Current | 128 mA |
| Logic Family | CB3T |
| Number of Inputs per Chip | 20 |
| Maximum Operating Supply Voltage | 3.6 V |
| Logic Function | Bus Switch |
| Configuration | 10 x 1:1 |
| Propagation Delay Test Condition | 50 pF |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Lead Finish | Gold |
| Rad Hard | No |
| Fabrication Technology | CMOS |
| Package | 48TSSOP |
| Replacement Part Number | PART-SN74CB3T16210DGGR |
| Weight | Contact us |
| Country of Origin | - |
