Please contact us for more photos of TLC2543IDW
| Part Number | TLC2543IDW |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 363980 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single SAR 66ksps 12-bit Serial 20-Pin SOIC Tube |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | TLC2543IDW |
| Datasheet download |  TLC2543IDW.pdf |
| Part Number | TLC2543IDW |
|---|---|
| Sampling Rate | 66 ksps |
| Mounting | Surface Mount |
| Supplier Package | SOIC |
| Digital Interface Type | Serial (SPI) |
| Input Type | Voltage |
| Voltage Supply Source | Single |
| Number of ADCs | 1 |
| Pin Count | 20 |
| Sample and Hold | Yes |
| Integral Nonlinearity Error | ±1 LSB |
| Differential Nonlinearity | ±1 LSB |
| No Missing Codes | 12 Bit |
| Maximum Single Supply Voltage | 5.5 V |
| Digital Supply Support | No |
| Full Scale Error | ±1 LSB |
| Number of Analog Inputs | 11 |
| Differential Input | No |
| MSL Level | 1 |
| Architecture | SAR |
| Polarity of Input Voltage | Unipolar |
| Voltage Reference | External |
| Single-Ended Input | Yes |
| Minimum Single Supply Voltage | 4.5 V |
| Input Voltage | 5 V |
| Product Dimensions | 12.8 x 7.52 x 2.35 mm |
| Lead Finish | Gold |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Resolution | 12 Bit |
| Input Signal Type | Single-Ended |
| Typical Single Supply Voltage | 5 V |
| Package | 20SOIC |
| Replacement Part Number | PART-TLC2543IDW |
| Weight | Contact us |
| Country of Origin | - |
