Please contact us for more photos of TPS62130AQRGTTQ1
| Part Number | TPS62130AQRGTTQ1 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 564930 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 3V to 17V 16-Pin QFN T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | TPS62130AQRGTTQ1 |
| Datasheet download |  TPS62130AQRGTTQ1.pdf |
| Part Number | TPS62130AQRGTTQ1 |
|---|---|
| Operating Temperature | -40 to 125 °C |
| Supplier Package | QFN |
| Switching Frequency | 2500 kHz |
| Switching Regulator | Yes |
| Product Dimensions | 3 x 3 x 0.95(Max) |
| Output Type | Adjustable |
| Maximum Output Current | 3 A |
| Load Regulation | 0.05(Typ) %/A |
| Maximum Input Voltage | 17 V |
| Line Regulation | 0.02(Typ) %/V |
| Lead Finish | Gold Over Nickel Palladium |
| Number of Outputs | 1 |
| Operating Supply Voltage | 3 to 17 V |
| Type | Step Down |
| Rad Hard | No |
| MSL Level | 2 |
| Minimum Input Voltage | 3 V |
| Output Voltage | 0.9 to 6 V |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Pin Count | 16 |
| Screening Level | Automotive |
| Package | 16QFN |
| Replacement Part Number | PART-TPS62130AQRGTTQ1 |
| Weight | Contact us |
| Country of Origin | - |
