Please contact us for more photos of CRCW0603120RJNEAC
| Part Number | CRCW0603120RJNEAC |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 406490 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film 0603 120 Ohm 5% 1 10W \u00b1200ppm \u00b0C Molded SMD Paper T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | CRCW0603120RJNEAC |
| Datasheet download |  CRCW0603120RJNEAC.pdf |
| Part Number | CRCW0603120RJNEAC |
|---|---|
| Failure Rate | |
| Military Standard | |
| Package Type | SMD |
| Type | Thick Film |
| Lead Finish | Pure Tin Over Nickel |
| Temperature Coefficient | 200 ppm/°C |
| Rad Hard | No |
| Pin Count | 2 |
| Moisture Sensitivity Level | 1 |
| Supplier Package | 0603 |
| Tolerance | 5 % |
| Case Style | Molded |
| Power Rating | 1|10 W |
| Termination Style | Wraparound |
| Maximum Processing Temperature | 260 °C |
| Mounting | Surface Mount |
| Resistance Value | 120 Ohm |
| Case Size | 0603 |
| Package Dimensions | 1.55 x 0.85 x 0.45 mm |
| Operating Temperature | -55 to 155 °C |
| Product Depth | 0.85 mm |
| Product Height | 0.45 mm |
| Product Length | 1.55 mm |
| Product Weight | 2 mg |
| Replacement Part Number | PART-CRCW0603120RJNEAC |
| Weight | Contact us |
| Country of Origin | - |
