IHLP2020BZER3R3M1A Vishay

IHLP2020BZER3R3M1A Images

Please contact us for more photos of IHLP2020BZER3R3M1A

Part Number IHLP2020BZER3R3M1A
Manufacturer Vishay
Quantity in stock 465270 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind High Current Shielded Wirewound 3.3uH 20% 100KHz 4.1A 2020 T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level IHLP2020BZER3R3M1A
Datasheet download IHLP2020BZER3R3M1A.pdf
Request Quotation for IHLP2020BZER3R3M1A

IHLP2020BZER3R3M1A Specifications

Part Number IHLP2020BZER3R3M1A
Protection Style Shielded
Pin Count 2
Rad Hard No
Package/Case 2020
Supplier Package 2020
Operating Temperature -55 to 125 °C
Technology Wirewound
MSL Level 1
Tolerance 20 %
Max Processing Temp 260
Test Frequency 100 kHz
Maximum DC Resistance 81.3
Maximum DC Current
Maximum Self Resonant Frequency
Inductance 4.7
Product Dimensions 5.49 x 5.18 x 3(Max)
Lead Finish Tin Over Nickel
Type High Current
Product Depth 5.18 mm
Product Height 3(Max) mm
Product Length 5.49 mm
Replacement Part Number PART-IHLP2020BZER3R3M1A
Weight Contact us
Country of Origin -
