Please contact us for more photos of ILC0402ER15NJ
| Part Number | ILC0402ER15NJ |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 730400 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind High Frequency Multi-Layer 15nH 5% 100MHz 8Q-Factor Ceramic 250mA 0402 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | ILC0402ER15NJ |
| Datasheet download |  ILC0402ER15NJ.pdf |
| Part Number | ILC0402ER15NJ |
|---|---|
| Pin Count | 2 |
| Minimum Quality Factor | 8@100MHz |
| Package Dimensions | 1 x 0.5 x 0.5 mm |
| Rad Hard | No |
| Tolerance | 5 % |
| Maximum Processing Temperature | 260 °C |
| Maximum DC Resistance | 550 MOhm |
| Operating Temperature | -55 to 125 °C |
| Core Material | Ceramic |
| Test Frequency | 100 MHz |
| Inductance | 15 nH |
| Maximum DC Current | 250 mA |
| Maximum Self Resonant Frequency | 2.5 GHz |
| Moisture Sensitivity Level | 1 |
| Technology | Multi-Layer |
| Package/Case | 0402 |
| Supplier Package | 0402 |
| Lead Finish | Tin Over Nickel |
| Type | High Frequency |
| Product Depth | 0.5 mm |
| Product Height | 0.5 mm |
| Product Length | 1 mm |
| Replacement Part Number | PART-ILC0402ER15NJ |
| Weight | Contact us |
| Country of Origin | - |
