Please contact us for more photos of ACML-0603H-601-T
| Part Number | ACML-0603H-601-T |
|---|---|
| Manufacturer | Abracon |
| Quantity in stock | 833810 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Chip Bead Shielded Multi-Layer 600 Ohm 25% 100MHz Ferrite 800mA 0603 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | ACML-0603H-601-T |
| Datasheet download |  ACML-0603H-601-T.pdf |
| Part Number | ACML-0603H-601-T |
|---|---|
| Type | Chip Bead |
| Maximum DC Resistance | 350 MOhm |
| Maximum Processing Temperature | 260 °C |
| Core Material | Ferrite |
| Rad Hard | No |
| Impedance | 600 Ohm |
| Supplier Package | 0603 |
| Pin Count | 2 |
| Tolerance | 25 % |
| Maximum DC Current | 800 mA |
| Operating Temperature | -55 to 125 °C |
| Package Dimensions | 1 x 0.8 x 0.8 mm |
| Protection Style | Shielded |
| Test Frequency | 100 MHz |
| Technology | Multi-Layer |
| Lead Finish | Tin Over Nickel |
| Package/Case | 0603 |
| Product Depth | 0.8 mm |
| Product Height | 0.8 mm |
| Product Length | 1 mm |
| Replacement Part Number | PART-ACML-0603H-601-T |
| Weight | Contact us |
| Country of Origin | - |
