Please contact us for more photos of BZX585-B13,115
| Part Number | BZX585-B13,115 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 852610 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 13V 2% 300mW 2-Pin SOD-523 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BZX585-B13,115 |
| Datasheet download |  BZX585-B13,115.pdf |
| Part Number | BZX585-B13,115 |
|---|---|
| Rad Hard | No |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Typical Voltage Temperature Coefficient | 8.8 mV/K |
| Product Dimensions | 1.25 x 0.85 x 0.65 mm |
| Type | Voltage Regulator |
| Lead Finish | Tin |
| Supplier Package | SOD-523 |
| Test Current | 5 mA |
| ESD Protection | No |
| Operating Temperature | -65 to 150 °C |
| Maximum Power Dissipation | 300 mW |
| Maximum Zener Impedance | 10 Ohm |
| Max Processing Temp | 260 |
| Maximum Reverse Leakage Current | 0.1 uA |
| Zener Voltage Tolerance | 2 % |
| Pin Count | 2 |
| Nominal Zener Voltage | 13 V |
| Configuration | Single |
| Package | 2SOD-523 |
| Replacement Part Number | PART-BZX585-B13,115 |
| Weight | Contact us |
| Country of Origin | - |
