Please contact us for more photos of N3431-6202RB
| Part Number | N3431-6202RB |
|---|---|
| Manufacturer | 3M |
| Quantity in stock | 279060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Ejector Header HDR 34 POS 2.54mm Solder ST Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | N3431-6202RB |
| Datasheet download |  N3431-6202RB.pdf |
| Part Number | N3431-6202RB |
|---|---|
| Max Processing Temp | 260 |
| Rad Hard | No |
| Pitch | 2.54 mm |
| Housing Material | Polychlorinated Terphenyl |
| Contact Plating | Gold Over Nickel |
| Contact Material | Copper Alloy |
| Operating Temperature | -55 to 105 °C |
| Lead Finish | Matte Tin |
| Termination Method | Solder |
| Housing Color | Black |
| Mounting | Through Hole |
| Product Dimensions | 62.61 x 8.6 x 24.6 mm |
| Body Orientation | Straight |
| MSL Level | 1 |
| Gender | HDR |
| Product Depth | 8.6 mm |
| Product Height | 24.6 mm |
| Product Length | 62.61 mm |
| Replacement Part Number | PART-N3431-6202RB |
| Weight | Contact us |
| Country of Origin | - |
