Please contact us for more photos of SMB2.5R-2
| Part Number | SMB2.5R-2 |
|---|---|
| Manufacturer | API Delevan |
| Quantity in stock | 656820 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Bead Shielded 490Ohm 100MHz Ferrite 9.5A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | SMB2.5R-2 |
| Datasheet download |  SMB2.5R-2.pdf |
| Part Number | SMB2.5R-2 |
|---|---|
| Lead Finish | Matte Tin |
| Protection Style | Shielded |
| Package/Case | 11.68 X 7.45 X 5.08 |
| Test Frequency | 100 MHz |
| Product Dimensions | 11.68 x 7.45 x 5.08 mm |
| Max Processing Temp | 260 |
| Core Material | Ferrite |
| Operating Temperature | -40 to 125 °C |
| Type | Bead |
| Maximum DC Resistance | 5 mOhm |
| Maximum DC Current | 9.5 A |
| Product Depth | 7.45 mm |
| Product Height | 5.08 mm |
| Product Length | 11.68 mm |
| Replacement Part Number | PART-SMB2.5R-2 |
| Weight | Contact us |
| Country of Origin | - |
