Please contact us for more photos of 245077030112861+
| Part Number | 245077030112861+ |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 224780 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board RCP 30 POS 1mm Solder ST SMD T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 245077030112861+ |
| Datasheet download |  245077030112861+.pdf |
| Part Number | 245077030112861+ |
|---|---|
| Mounting | Surface Mount |
| Termination Method | Solder |
| Contact Plating | Gold |
| Product Dimensions | 26 x 7 mm |
| Gender | RCP |
| Body Orientation | Straight |
| Contact Material | Copper Alloy |
| Pitch | 1 mm |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Lead Finish | Tin/Copper |
| Housing Material | Plastic |
| Product Depth | 7 mm |
| Product Length | 26 mm |
| Replacement Part Number | PART-245077030112861+ |
| Weight | Contact us |
| Country of Origin | - |
