Please contact us for more photos of CK05BX103K
| Part Number | CK05BX103K |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 540100 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 0.01uF 100V X7R 10% Radial 5.08mm 125\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | CK05BX103K |
| Datasheet download |  CK05BX103K.pdf |
| Part Number | CK05BX103K |
|---|---|
| Dielectric | X7R |
| Wire Form | Outside Bend |
| Failure Rate | |
| Voltage(DC) | 100 V |
| Capacitance Value | 0.01 uF |
| Military Standard | MIL-C-11015 |
| Tolerance | 10 % |
| Termination Style | Radial |
| Case Style | Molded |
| Package/Case | 4.83 X 2.29 X 4.83 |
| Product Dimensions | 4.83 x 2.29 x 4.83 mm |
| Rad Hard | No |
| Lead Diameter | 0.64 mm |
| Operating Temperature | -55 to 125 °C |
| Lead Pitch For Radial | 5.08 mm |
| Lead Finish | Tin/Lead |
| Mounting | Through Hole |
| Type | Radial |
| Product Depth | 2.29 mm |
| Product Height | 4.83 mm |
| Product Length | 4.83 mm |
| Replacement Part Number | PART-CK05BX103K |
| Weight | Contact us |
| Country of Origin | - |
