Please contact us for more photos of SDR0805-220ML
| Part Number | SDR0805-220ML |
|---|---|
| Manufacturer | Bourns |
| Quantity in stock | 191050 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Wirewound 22uH 20% 1KHz 20Q-Factor Ferrite 1.5A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | SDR0805-220ML |
| Datasheet download |  SDR0805-220ML.pdf |
| Part Number | SDR0805-220ML |
|---|---|
| Operating Temperature | -40 to 125 °C |
| Rad Hard | No |
| Tolerance | 20 % |
| Test Frequency | 1 kHz |
| Core Material | Ferrite |
| Technology | Wirewound |
| Max Processing Temp | 230 |
| Type | Power |
| Package/Case | 7.8 X 5.3 |
| Product Dimensions | 5.3 mm |
| MSL Level | 1 |
| Lead Finish | Tin |
| Product Diameter | 7.8 mm |
| Product Height | 5.3 mm |
| Replacement Part Number | PART-SDR0805-220ML |
| Weight | Contact us |
| Country of Origin | - |
