Please contact us for more photos of SDR1806-680ML
| Part Number | SDR1806-680ML |
|---|---|
| Manufacturer | Bourns |
| Quantity in stock | 126040 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Wirewound 68uH 20% 100KHz 22Q-Factor Ferrite 2.1A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | SDR1806-680ML |
| Datasheet download |  SDR1806-680ML.pdf |
| Part Number | SDR1806-680ML |
|---|---|
| Rad Hard | No |
| Operating Temperature | -40 to 125 °C |
| MSL Level | 1 |
| Test Frequency | 100 kHz |
| Max Processing Temp | 250 |
| Product Dimensions | 18.6 x 14.3 x 6.9 mm |
| Tolerance | 20 % |
| Lead Finish | Tin/Copper |
| Type | Power |
| Technology | Wirewound |
| Core Material | Ferrite |
| Package/Case | 18.6 X 14.3 X 6.9 |
| Product Depth | 14.3 mm |
| Product Height | 6.9 mm |
| Product Length | 18.6 mm |
| Replacement Part Number | PART-SDR1806-680ML |
| Weight | Contact us |
| Country of Origin | - |
