HCF1007-2R2-R Eaton

HCF1007-2R2-R Images

Please contact us for more photos of HCF1007-2R2-R

Part Number HCF1007-2R2-R
Manufacturer Eaton
Quantity in stock 846720 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind Power Wirewound 2.2uH 10% 100KHz Ferrite 10.7A T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level HCF1007-2R2-R
Datasheet download HCF1007-2R2-R.pdf
Request Quotation for HCF1007-2R2-R

HCF1007-2R2-R Specifications

Part Number HCF1007-2R2-R
Package/Case 10.3 X 8.1 X 6.65
Product Dimensions 10.3 x 8.1 x 6.65 mm
Operating Temperature -40 to 125 °C
Rad Hard No
Tolerance 10 %
Core Material Ferrite
Technology Wirewound
Maximum DC Resistance
Inductance
Impedance
Minimum Quality Factor
Maximum DC Current
Maximum Self Resonant Frequency
Type Power
Test Frequency 100 kHz
Product Depth 8.1 mm
Product Height 6.65 mm
Product Length 10.3 mm
Replacement Part Number PART-HCF1007-2R2-R
Weight Contact us
Country of Origin -
