Please contact us for more photos of MAX1227BCEE+T
| Part Number | MAX1227BCEE+T |
|---|---|
| Manufacturer | Maxim Integrated |
| Quantity in stock | 307120 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single SAR 300ksps 12-bit Serial 16-Pin QSOP T R |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | MAX1227BCEE+T |
| Datasheet download |  MAX1227BCEE+T.pdf |
| Part Number | MAX1227BCEE+T |
|---|---|
| Number of ADCs | 1 |
| Differential Input | Yes |
| Minimum Single Supply Voltage | 2.7 V |
| Pin Count | 16 |
| Sampling Rate | 300 ksps |
| Operating Temperature | 0 to 70 °C |
| Typical Single Supply Voltage | 3 V |
| Polarity of Input Voltage | Unipolar|Bipolar |
| Maximum Single Supply Voltage | 3.6 V |
| Supplier Package | QSOP |
| Rad Hard | No |
| Integral Nonlinearity Error | ±1 LSB |
| Voltage Supply Source | Single |
| Single-Ended Input | Yes |
| Max Processing Temp | 260|300 |
| Full Scale Error | ±4 LSB |
| Sample and Hold | Yes |
| Mounting | Surface Mount |
| Input Type | Voltage |
| Input Signal Type | Single-Ended|Differential |
| Product Dimensions | 4.98 x 3.99 x 1.55 mm |
| Differential Nonlinearity | ±1 LSB |
| Input Voltage | 2.5|±1.25 V |
| Lead Finish | Matte Tin |
| Typical Power Dissipation | 1.86 mW |
| Voltage Reference | Internal|External |
| Number of Analog Inputs | 8|4 |
| MSL Level | 1 |
| Maximum Power Dissipation | 667 mW |
| Digital Interface Type | Serial (3-Wire, SPI, QSPI, Microwire) |
| Package | 16QSOP |
| Replacement Part Number | PART-MAX1227BCEE+T |
| Weight | Contact us |
| Country of Origin | - |
